HIGH VISCOSITY SYSTEM (HVS)

Unloading drums filled with highly viscous liquids has never been easier. Our High Viscosity System (HVS) is designed to simplify this task, offering automated efficiency and exceptional product-saving capabilities. With HVS, you’ll experience a smooth unloading process, allowing you to focus on other critical tasks while achieving up to a 99% product removal rate. Say hello to effortless drum unloading with HVS.

Our drum unloading system is equipped with a hygienic double diaphragm pump featuring lifting and lowering capabilities, designed for the efficient unloading of 200-liter drums. Notably mobile, this system offers the convenience of unloading a drum containing double-concentrated tomato paste in under two minutes, showcasing its remarkable speed and efficiency in action.

KEY FEATURES

  • Quick unloading of the drums: up to 400 liters per minute, depending on the liquid properties and discharge pressure.
  • 99% product extraction: product savings thanks to the applied scraping lid.
  • High process safety and time-saving benefits: brought by the control system
rachid No Comments

SLES MIXING & DILUTION UNIT

SLES or Sodium Laureth Sulfate, is an organic chemical compound, called a surfactant, with excellent cleansing and foaming properties. For this reason, it is an ingredient of various detergents, household products, soaps, and shampoos.

SLES is usually supplied to the producers of the above liquids at a concentration of 70% and due to its physical properties, this concentrated solution is difficult to handle and must be diluted below 27% before using it in the process line. Buying SLES at a 27% concentration can be a huge financial investment for companies, however, with Tapflo’s SLES Mixing and Dilution Unit customers can purchase SLES at 70% concentration and dilute it themselves. Our system allows continuous dilution with maximum efficiency and safety, reducing the cost to the company in the long run.

Features

  • Precise diluting of SLES or other surfactant to the required concentration and flow rate.
  • Immediate operation gives homogenous and stable in time liquid.
  • Brings energy, time, and space savings (compared to other dilution methods).
  • Continuous or batch supply of SLES solution at a given concentration.
  • Constant tracing and recording of operation parameters.
  • Small in size, lightweight, and well-thought-out construction.
  • Local or remote control over the Unit.
  • Possible extensions: dosing of additional ingredients, feeding 70% SLES solution directly from a road tanker.

Benefits

  • Savings of chemicals with exact SLES volume.
  • High quality of the on-site prepared SLES solution.
  • Energy-efficient and reduce the total cost of the final product.
  • Independence from deliveries of diluted SLES.
  • Flexibility and continuity of production.
  • Significant cost reduction of SLES purchase, transportation, and storage.
  • Additional savings on the warehouse space.

TECHNICAL DATA

Flow rate (SLES solution):Standardized systems: 5 m3/h and 10 m3/h.
Custom-built systems: up to 30 m3/h.
Discharge pressure:up to 6 bar-g
Concentration of obtained SLES solution:The user can select the value between 0 and 27 %
rachid No Comments

PT HIGH PRESSURE HOSE PUMPS

APPLICATIONS

industrial, paint, waste water treatment, food, paper mills, chemical, biogas, recycling, mining, building

  • Capacity 0 – 60 m3/h (up to 120 m3/h twin head)
  • shoe design
  • lubricant type: glycerine FDA
  • housing material: nodular cast iron
  • 15 sizes available
  • horizontal and vertical gear motor position

FEATURES & BENEFITS

  • Pumping challenging liquids
    Hose pumps are suitable for efficiently pumping highly abrasive, corrosive, and viscous liquids containing particles.
  • Ease maintenance, reduced downtime
    Hassle-free maintenance and minimal downtime due to few components and no seals required.
  • Easy operation
    User-friendly operation without the need for specialized personnel.
  • Cost-effective solution
    Total Cost of Ownership (TCO) for economical pumping solutions.
  • Turbulence-free performance
    Smooth and gentle pumping even with highly abrasive or sensitive liquids, minimizing wear and ensuring optimal operations.
  • Extensive configuration options
    The pump connection offers a diverse range of types and orientations.
  • Self-priming
    Efficient self-priming with superior suction capacity up to -0.9 bar.
  • Handling high viscosity
    Reliable performance with the ability to pump liquids with viscosities up to 100,000cP.
  • Reversible operation
    Versatile functionality for various applications with an easy change of rotation direction.
  • Adjustable flow and precise dosing
    Flexibility in flow rates and precise dosing accuracy of approximately ±5% by adjusting the speed, such as with a frequency converter.
  • Safe to run dry
    Safe to run dry, eliminating the need for monitoring and ensuring ease of use and peace of mind.
foritech morocco
rachid No Comments

Pompe vide fut

foritech

Besoin d’aller au fond des choses ?

Pour vider simplement et en toute sécurité vos bidons, fûts, containers et cuves, GRUN pompes et Redwood Industries, mettent à votre disposition une gamme complète de pompes vide futs électriques ou pompes vide futs pneumatiques, ainsi que des pompes vide containers de haute qualité !

rachid No Comments

POMPE FILTRE PRESS TAPFLO

Les pompes Tapflo pour les applications de filtre-presse sont des unités compactes qui peuvent être montées directement sur le filtre-presse. La conception et la fonctionnalité permettent à l’utilisateur un pressage direct des boues, jusqu’à 16 bars. L’unité est livrée avec un renfort de boîtier, un surpresseur externe pouvant même doubler la pression d’entrée et une vanne d’air haute pression.

Tapflo AODD

rachid No Comments

POMPES CENTRIFUGE PREMIUM

FORITECH

La série de pompes premium de Tapflo avec des performances supérieures

Grâce à la construction robuste et à une conception compacte et fiable, les pompes centrifuges hautes performances CTX assurent un fonctionnement sans défaillance à long terme et donc des temps d’arrêt courts. Les pompes CTX sont disponibles en exécution hygiénique (CTX H) et industrielle (CTX I)

rachid No Comments

POMPE CENTRIFUGE VERTICAL INOX

ℹ️ 𝗣𝗿𝗼𝗱𝘂𝗰𝘁 𝗰𝗼𝗱𝗲: CTV40-12.5

𝗣𝗿𝗼𝗱𝘂𝗰𝘁 𝗱𝗲𝘀𝗰𝗿𝗶𝗽𝘁𝗶𝗼𝗻: Pompe centrifuge verticale CTV en acier inoxydable avec moteur 2,2 kW.

🛠️ 𝗔𝗽𝗽𝗹𝗶𝗰𝗮𝘁𝗶𝗼𝗻: La pompe est utilisée dans la grande usine européenne de bougies. Le même client utilise également plusieurs pompes CT.
La pompe CTV fonctionne dans une application pour la production de «flocons de paraffine».
La plupart des bougies ne sont pas coulées à partir de cire de paraffine fondue mais sont pressées à partir de petits flocons de paraffine.
Dans cette application, la pompe CTV pompe de la cire de paraffine fondue chaude vers des buses créant un brouillard de paraffine. La brume se refroidit dans l’air et crée de la «neige de paraffine» qui tombe sur le rouleau refroidi, puis elle est grattée du rouleau, créant des flocons de paraffine utilisés pour la production de bougies.

🌐 𝗣𝗿𝗼𝗱𝘂𝗰𝘁 𝘄𝗲𝗯𝗽𝗮𝗴𝗲𝘀: https://www.tapflo.com/en/centrifugal-pumps/vertical-pumps/ctv-40-12-5-stireless
